Single Row Tapered Roller Bearings

Single Row Tapered Bearings

Single row tapered bearings have a collapsible design. The inner unit consisting of an inner ring with a set of rollers and a cage can be installed separately from the outer ring.

If the axial loads act in two directions, two single-row tapered bearings (in pairs) are mounted in the bearing unit, equipped with a spacer ring providing the necessary clearance between the bearings. Also, for these purposes, a two-row or four-row angular contact roller bearing is often used.

To buy single row tapered bearings at a low price, contact us in any convenient way.

Designation Formula

Item	Description
Basic designation	—
Internal design	B, R
Cage	(without suffix, P)
Accuracy	(without suffix, P0(ABEC-1),P6(ABEC-3))

Prefix and Suffix Designations

Suffix	Meaning
without suffix	Stamped steel cage, roller centered; dimensional and running accuracy to normal class
B	Contact angle is greater than a standard bearing contact angle
P	Polymer cage
P6	Dimensional and running accuracy to ISO tolerance class 6
R	The outer ring with one rib

Single Row Tapered Roller Bearings

30200 Series Taper Roller Bearing

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
30202	15	35	11	0.05	7.5	7.5	10500	15000
30203	17	40	12	0.08	13.2	20.6	9500	13000
30204	20	47	14	0.13	26.9	28.2	8450	11500
30205	25	52	15	0.15	32	35.5	7300	10000
30206	30	62	16	0.16	41.6	45.8	6200	8500
30207	35	72	17	0.33	51.9	56.4	5200	7100
30208	40	80	19.75	0.45	59.9	67.6	4600	6400
30209	45	85	20.75	0.49	65	73.8	4300	6000
30210	50	90	21.75	0.54	74.4	89.3	3600	5000
30211	55	100	22.75	0.71	93.2	105	3600	5000
30212	60	110	23.75	0.93	105.8	121	3300	4500
30213	65	120	24.75	1.13	123	140.9	2900	4000
30214	70	125	26.25	1.25	128.1	160.9	2900	4000
30215	75	130	27.25	1.42	140.6	172	2700	3700
30216	80	140	28.25	1.67	151.7	187	2600	3600
30217	85	150	30.25	2.11	186	219.7	2500	3300
30218	90	160	32.5	2.52	195.7	251.3	2300	3100
30219	95	170	34.5	3.10	218.7	279	2100	2900
30220	100	180	37	3.63	256.7	333.7	2000	2800
30221	105	190	38	3.80	283.3	374	2000	2800
30222	110	200	40	4.05	312	414	1800	2400
30224	120	215	43.5	6.28	341.7	462.3	1600	2200
30230	150	270	49	10.70	422	565	1500	2000
30244	220	400	70	34.90	927.7	1305.7	800	1100

30300 Series Taper Roller Bearing

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
30302	15	42	14.25	0.10	22.8	20.8	8900	13500
30303	17	47	15.25	0.13	27.6	25	9200	12000
30304	20	52	16.25	0.17	33.1	31.9	7900	10500
30305	25	62	18.25	0.27	45.9	44.4	6500	8900
30306	30	72	20.75	0.41	57	57.4	5400	7400
30307	35	80	22.75	0.54	72.2	75.2	4800	6000
30308	40	90	25.25	0.77	88.4	98.6	4300	5900
30309	45	100	27.25	1.02	109.7	122.6	3800	5200
30310	50	110	29.25	1.31	137	144.3	3700	4900
30311	55	120	31.5	1.67	152.3	168	3300	4400
30312	60	130	33.5	2.06	170	198	3000	4000
30313	65	140	36	2.55	194	228.7	2800	3700
30314	70	150	38	3.09	224.3	264.3	2600	3500
30315	75	160	40	3.68	247.7	294	2400	3200
30316	80	170	42.5	4.41	283.7	341.7	2200	3100
30317	85	180	44.5	5.13	305.7	367.7	2000	2800
30318	90	190	46.5	5.93	332.7	402.7	1900	2600
30319	95	200	49.5	6.92	348.3	418.3	1800	2500
30320	100	215	51.5	8.47	407	496.7	1700	2400
30321	105	225	53.5	9.66	443	548.7	1600	2200
30322	110	240	54.5	12.50	475.7	586	1500	2100
30324	120	260	59.5	14.50	562.3	705	1400	1900

32200 & 32300 Series Taper Roller Bearing

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
32202	15	35	11	0.10	-	-	-	-
32203	17	40	17.25	0.10	30.6	30.9	9100	11900
32204	20	47	19.25	0.17	35.8	39	8700	11800
32205	25	52	19.25	0.19	37.9	45.4	7500	10200
32206	30	62	21.25	0.30	50.1	57.2	6200	8500
32207	35	72	24.25	0.46	66.8	78.1	5100	7000
32208	40	80	24.75	0.56	74.5	86.7	4500	6200
32209	45	85	24.75	0.60	83.1	97.3	4200	5800
32210	50	90	24.75	0.64	86.8	103.7	4100	5400
32211	55	100	26.75	0.88	106.9	132.8	3600	4800
32212	60	110	29.75	1.20	129.9	166.9	3200	4400
32213	65	120	32.75	1.58	156.6	204.9	2900	3900
32214	70	125	33.25	1.68	161.7	216	2800	3800
32215	75	130	33.25	1.76	163.7	218.7	2700	3700
32216	80	140	35.25	2.18	189	253.7	2600	3600
32217	85	150	38.5	2.75	216.1	291.7	2400	3200
32218	90	160	42.5	3.49	254.7	351.7	2300	3100
32219	95	170	45.5	4.32	296.7	414	2200	3000
32220	100	180	49	5.21	332.3	467	2200	3000
32221	105	190	53	6.38	377	540	2100	2800
32222	110	200	56	7.43	418.3	601.7	2000	2700
32224	120	215	61.5	9.42	463.3	686.7	1600	2200
32226	130	230	67.75	11.80	545	830	1500	2000
32228	140	250	71.75	14.88	633.7	973.3	1400	1900
32230	150	270	77	18.52	725.3	1120	1300	1700
32232	160	290	84	22.20	881.7	1405	1200	1600
32236	180	320	92	27.60	1018.3	1656.7	1100	1400
32238	190	340	97	35.40	1163.3	1873.3	1000	1300
32244	220	400	114	58.40	1592.5	2662.5	850	1100
32302	15	42	17	0.12	-	-	-	-
32303	17	47	15.25	0.13	35.9	34.8	8500	11000
32304	20	52	22.25	0.24	44.1	45.8	8000	10500
32305	25	62	25.25	0.38	60.8	64.2	6500	8500
32306	30	72	28.75	0.50	79.5	89.1	5500	7200
32307	35	80	32.75	0.79	97.7	111.4	4700	6300
32308	40	90	35.25	1.08	117.3	142.7	4200	5500
32309	45	100	38.25	1.48	145.3	179.3	3700	5000
32310	50	110	42.25	1.96	174.5	243	3300	4500
32311	55	120	45.5	2.46	201.3	260.3	3100	4300
32312	60	130	48.5	3.05	233.7	301.3	2900	3900
32313	65	140	51	3.40	266	338.7	2800	3700
32314	70	150	54	4.53	300	394.3	2600	3500
32315	75	160	58	5.54	345	458	2400	3200
32316	80	170	61.5	6.60	389.3	515	2200	3000
32317	85	180	63.5	7.57	406.7	541.7	2000	2800
32318	90	190	67.5	9.06	461.7	629.3	1900	2700
32319	95	200	71.5	11.00	507.3	678.3	1800	2500
32320	100	215	77.5	13.10	579.3	788.3	1700	2400
32322	110	240	84.5	17.70	672	910	1500	2100
32324	120	260	90.5	22.40	779.3	1098.3	1400	1900
32334	170	360	127	58.00	1505	2300	1000	1300

32000 Series Taper Roller Bearing

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
32004	20	42	15	0.10	24	28.9	9200	13000
32005	25	47	15	0.11	26.6	30.9	8000	10500
32006	30	55	17	0.17	36.6	44.3	6700	8700
32007	35	62	18	0.22	42.3	52.7	5900	8100
32008	40	68	19	0.28	51.3	66.8	5100	7000
32009	45	75	20	0.35	58.2	77.5	4600	6300
32010	50	80	20	0.38	63	90.1	4300	5900
32011	55	90	23	0.57	79	113.2	3800	5200
32012	60	95	23	0.61	86.6	120.8	3600	4900
32013	65	100	23	0.64	86.8	126.3	3300	4500
32014	70	110	25	0.88	101.4	153.3	3200	4300
32015	75	115	25	0.92	105.3	162.7	3000	4000
32016	80	125	29	1.29	136	213.2	2800	3700
32017	85	130	29	1.35	139.3	221.2	2700	3600
32018	90	140	32	1.76	162	256.2	2600	3400
32019	95	145	32	1.85	171	276.7	2500	3300
32020	100	150	32	1.92	173.3	294	2400	3200
32021	105	160	35	2.44	202.3	335.7	2300	3100
32022	110	170	38	3.09	238.3	390.2	2200	3000
32024	120	180	38	3.32	247	421.7	2100	2800
32026	130	200	45	5.05	321.3	548.3	1900	2500
32028	140	210	45	5.37	331.7	581.7	1600	2100
32032	160	240	51	7.92	436	779.1	1300	1800
32036	180	280	64	14.10	678.8	1177.3	1200	1600
32038	190	290	64	14.80	725.3	1213.7	1100	1500
32040	200	310	70	19.10	779	1389.7	1000	1400
32044	220	340	76	24.70	926.7	1695.3	950	1300
32048	240	360	76	26.30	978.7	1788	900	1200
32052	260	400	87	40.00	1187	2241.7	800	1000
32056	280	420	87	41.20	1120	2364.7	700	1000
32060	300	460	100	55.90	1528	2922.6	670	900
32064	320	480	100	64.00	1558.3	3046.3	630	850

33000 Series Taper Roller Bearing

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
33005	25	47	17	0.13	—	—	—	—
33006	30	55	20	0.21	—	—	—	—
33007	35	62	21	0.27	—	—	—	—
33008	40	68	22	0.33	—	—	—	—
33009	45	75	24	0.42	78	109.6	5900	5300
33010	50	80	24	0.46	63.9	92.6	4700	4700
33011	55	90	27	0.67	88	116.5	4800	4200
33012	60	95	27	0.71	90	122.5	4500	4000
33013	65	100	27	0.78	94	130.5	4300	3700
33014	70	110	31	1.12	117	176.4	3700	3300
33015	75	115	31	1.17	121	205.4	3400	3300
33016	80	125	36	1.65	151	257.4	3400	3100
33017	85	130	36	1.73	165	279.4	3400	3300
33018	90	140	39	2.25	184	302.4	2900	2900
33019	95	145	39	2.34	187	319.3	2800	2800
33020	100	150	39	2.43	191	331.3	2600	2800
33021	105	160	43	3.06	209	366.3	2400	2400
33022	110	170	47	3.87	253	450.3	2200	2200
33024	120	180	48	4.22	263	486.2	2000	2000
33026	130	200	55	6.32	—	—	—	—
33028	140	210	56	6.75	—	—	—	—
33030	150	225	59	8.26	—	—	—	—
33205	25	52	22	0.23	42.5	51.1	8000	8700
33206	30	62	25	0.37	54.6	58.8	6600	6600
33207	35	72	28	0.56	71.9	87.8	5800	5800
33208	40	80	32	0.78	89	112.6	5300	5300
33209	45	85	32	0.82	92	122.6	4700	4700
33210	50	90	32	0.90	97	136.5	4400	4400
33211	55	100	35	1.21	117	162.5	4000	4000
33212	60	110	38	1.61	143	201.5	3700	3700
33213	65	120	41	2.06	175	243.4	3400	3300
33214	70	125	41	2.17	171	242.4	3100	3100
33215	75	130	41	2.27	178	255.4	3100	3100
33216	80	140	46	3.02	213	319.3	2900	2900
33217	85	150	49	3.70	243	366.3	2400	2400
33218	90	160	55	4.80	—	—	—	—
33220	100	180	63	6.97	—	—	—	—
33108	40	75	26	0.51	67.8	87.4	5300	5300
33109	45	80	26	0.56	82	97.6	5000	5000
33110	50	85	26	0.60	73	104.6	4700	4700
33111	55	95	30	0.88	94	133.5	4200	4200
33112	60	100	30	0.94	99	145.5	3700	3700
33113	65	110	34	1.32	121	177.5	3900	3900
33114	70	120	37	1.73	146	213.4	3400	3300
33115	75	125	37	1.82	150	225.4	3200	3100
33116	80	130	37	1.93	152	238.4	3500	3300
33117	85	140	41	2.50	187	289.3	2600	2600
33118	90	150	45	3.20	213	332.4	2900	2900
33119	95	160	49	4.03	—	—	—	—

Single Tapered Roller Bearings with large Cone Angle

Designation	d (mm)	D (mm)	B (mm)	Weight (kg)	Dynamic (kN)	Static (kN)	Grease (r/min)	Oil (r/min)
27305	25	62	18.25	0.26	—	—	—	—
27306	30	72	20.75	0.39	—	—	—	—
27307	35	80	22.75	0.52	—	—	—	—
27308	40	90	25.25	0.77	—	—	—	—
27309	45	100	27.25	0.95	—	—	—	—
27310	50	110	29.25	1.24	—	—	—	—
27311	55	120	31.5	1.58	—	—	—	—
27312	60	130	33.5	1.91	—	—	—	—
27313	65	140	36	2.40	—	—	—	—
27314	70	150	38	2.95	—	—	—	—
27315	75	160	40	3.50	—	—	—	—
27316	80	170	42.5	4.00	—	—	—	—
27317	85	180	44.5	4.70	—	—	—	—
27318	90	190	46.5	5.90	—	—	—	—
27319	95	200	49.5	6.00	—	—	—	—
32306 B	30	72	28.75	0.60	79.5	89.1	5500	7200
32307 B	35	80	32.75	0.80	94	109.3	4600	6300
32310 B	50	110	42.25	1.96	168.5	220.3	3300	4400
32311 B	55	120	45.5	2.54	201.3	260.3	3100	4300
32312 B	60	130	48.5	2.80	224.3	299.3	2900	3600
32313 B	65	140	51	3.75	266.7	347.2	2600	3500
32314 B	70	150	54	4.56	298.3	394.7	2500	3400
32315 B	75	160	58	5.53	321.7	439.7	2200	3000
32316 B	80	170	61.5	5.70	389.3	515	2100	2900
32317 B	85	180	63.5	7.50	406.7	541.7	2000	2800
27705	25	62	18.25	0.27	—	—	—	—
27706	30	72	24.5	0.47	—	—	—	—
27709	45	100	31.75	1.04	—	—	—	—
27711	55	125	37	2.10	—	—	—	—
27714	70	140	39	2.80	—	—	—	—
27715	75	150	42	3.25	—	—	—	—
27719	95	160	38	3.00	—	—	—	—
27907	35	70	24.25	0.43	—	—	—	—
27908	40	80	38	0.75	—	—	—	—
27911	55	100	39.75	1.23	—	—	—	—
31303	17	47	15.25	0.13	—	—	—	—
31304	20	52	16.25	0.17	29.5	28.7	9500	9900
31305	25	62	18.25	0.27	38.2	40.96	8300	8300
31306	30	72	20.75	0.40	48.7	53.55	7200	7200
31307	35	80	22.75	0.53	62.5	68.84	6200	6200
31308	40	90	25.25	0.75	82.1	87.73	5400	5400
31309	45	100	27.25	1.00	101.6	105.3	4800	4800
31310	50	110	29.25	1.27	116.3	121.3	4300	4300
31311	55	120	31.5	1.62	128	142.3	3900	3900
31312	60	130	33.5	2.01	149	166.7	3700	3700
31313	65	140	36	2.47	168.8	191.7	3500	3500
31314	70	150	38	3.01	186	220.2	3200	3200
31315	75	160	40	3.54	210	247.3	3100	2900
31316	80	170	42.5	4.20	228	272	2700	2700
31317	85	180	44.5	5.10	245.3	290.3	2500	2500
31318	90	190	46.5	5.90	268	318.3	2400	2400
31319	95	200	49.5	6.95	295	357.3	2300	2300
31320	100	215	56.5	9.07	386	474	2100	2100
31322	110	240	63	12.23	461.3	591	1400	1900
31324	120	260	67.5	15.40	547	708.3	1300	1800
31328	140	300	77	23.00	694.3	919.3	1100	1500
31336	180	380	97	46.00	—	—	—	—
31340	200	420	107	63.00	—	—	—	—

上一条： 暂无上一条数据

下一条： Double Row Taper Bearing

Single Row Taper Bearing

Single Row Tapered Bearings

Designation Formula

Prefix and Suffix Designations
